Personal Air Samplers

• Equipment Type
• Personal Air Sampler

• Accuracy
• 5% of set point

• Application
• Personal exposure monitoring to airborne contaminants

• Automation Grade
• Automatic

• Capacity
• 1 specimen

• Control Mode
• Automatic

• Display Type
• LCD Digital Display

• Features
• Lightweight, Portable, Low noise, Battery operated, Belt clip

• Gas Pressure
• Atmospheric

• Humidity
• Up to 95% RH non-condensing

• Interface Type
• Tubing interface, Battery charging port

• Machine Weight
• 450 g

• Measuring Range
• 0.1 - 5.0 L/min

• Mounting Type
• Portable/Belt-Mounted

• Number of Specimens
• Single sample per operation

• Operating Voltage
• 9V DC

• Port Size
• 6 mm

• Power Supply
• Rechargeable battery (NiMH), 9V DC adaptor

• Resolution
• 0.01 L/min

• Response Time
• <1 second

• Specimen Size
• Standard filter cassette

• Temperature
• 5C to 45C operating

• Test Range
• 0.1 - 5.0 L/min (flow rate)

• Test Speed
• Variable, typically 1-5 L/min

• Usage
• For sampling airborne contaminants in occupational hygiene

• Equipment Type
• Personal Air Sampler

• Accuracy
• 5%

• Application
• Occupational Health, Workplace Monitoring

• Automation Grade
• Manual

• Capacity
• Single-sample

• Control Mode
• Manual On/Off

• Display Type
• LED Status Indicator

• Features
• Lightweight, Portable, Rechargeable, Low Noise

• Gas Pressure
• Atmospheric

• Hardness
• ABS Housing

• Humidity
• 85% RH (non-condensing)

• Interface Type
• Manual Hose Interface

• Machine Weight
• Approx. 0.7 kg

• Max Height
• 150 mm

• Measuring Range
• 1.0-4.0 L/min

• Mounting Type
• Belt Clip

• Number of Specimens
• 1 per sampling session

• Operating Voltage
• 12V DC

• Port Size
• 6 mm hose connector

• Power Supply
• Rechargeable Li-Ion Battery, 12V DC adapter

• Resolution
• 0.1 L/min

• Response Time
• Immediate start/stop

• Specimen Size
• Standard filter cassette (37 mm)

• Temperature
• 5C to 40C

• Test Range
• Up to 4.0 L/min flow

• Test Speed
• 1.0-4.0 L/min (adjustable)

• Usage
• Personal Air Quality Monitoring

• Equipment Type
• Personal Air Sampler

• Accuracy
• 5%

• Application
• Ambient, Personal and Indoor Air Sampling

• Automation Grade
• Automatic

• Capacity
• Up to 8 hour operation

• Control Mode
• Digital Keypad

• Display Type
• Digital LCD with Backlight

• Features
• Lightweight, Portable, Adjustable Flow, Battery Status Display

• Frequency
• 50 Hz

• Humidity
• 0-95% RH (non-condensing)

• Interface Type
• Push Button Digital

• Machine Weight
• 475g

• Measuring Range
• 1.0 L/min to 2.0 L/min

• Mounting Type
• Belt Clip

• Operating Voltage
• 230V AC

• Port Size
• 6 mm OD

• Power Supply
• NiMH Rechargeable Battery / 230V AC Adapter

• Resolution
• 0.01 L/min

• Response Time
• Immediate

• Temperature
• 5C to 40C

• Test Range
• Up to 9999 liters (adjustable)

• Test Speed
• 1.0 - 2.0 L/min (adjustable)

• Usage
• Personal Sampling for Respirable Particulates

• Equipment Type
• Personal Air Sampler

• Accuracy
• 5% of setting

• Application
• Occupational hygiene and air quality monitoring

• Automation Grade
• Semi-automatic

• Capacity
• Typically 8 hours on battery

• Control Mode
• Manual

• Display Type
• Digital

• Features
• Lightweight, Portable, Rechargeable, Digital display

• Humidity
• 0-95% RH (non-condensing)

• Machine Weight
• 450 g

• Measuring Range
• 1000-4000 ml/min

• Mounting Type
• Clip-on or belt-mounted

• Operating Voltage
• DC 6V (NiMH/AC Adapter)

• Power Supply
• NiMH rechargeable battery / AC adapter

• Response Time
• Immediate (real-time)

• Temperature
• -10C to +50C

• Usage
• Personal exposure measurement
